• Material: High Strength Polyurethane (Sticker Type but no Glue)
• Adhesion method : Bubble Clearing Dry Adhesive
• Protection Level : Impact + Sctraches
• Shock Absorbent
• Helf Healing without Glue dry apply
• 100% Crystal Clear Transperent material
• Surface Hardness : 9H Scratch resistance, Shatter Proof
• Oleophobic Coating to resist finger prints and other contaminates
• Anti-fingerprint, smooth,bubblefree, anti-oil, easy adsorption, no residue,repeat use,anti yellowing
• True Touch sensitivity and 100% super Transperency
Item No.: XG100-25SR25
Product Name | XG100-25SR25 | Test Method |
---|---|---|
Use film Thickness(um) | 145±8 | Thickness tester |
Base thickness(um) | 100±3 | Thickness tester |
Adhesive Thickness(um) | 25±2 | Thickness tester |
Coating thickness(um) | 18±3 | Thickness tester |
Release liner thickness(um) | 100±1 | Thickness tester |
Protection thickness(um) | 85±2 | Thickness tester |
Peel force of release film with adhesive (g/25mm) | 1~2g | JIS Z0237-1980(300mm/min) |
Peel force of protection film with coating film (g/25mm) | 1~3g | JIS Z0237-1980(300mm/min) |
Coating Contact Angle (degree) | ≥103 | XL Method |
light transmittance(%) | ≥90 | JIS K7361(D65) |
Harizonae (%) | ≦2 | JIS K7361(D65) |
Peeling force of steel plate (gf/25mm) | ≥500 | JIS Z0237-1980(300mm/min) |
